Cosmo Tractor Tillers

Best in class tillers are here!

Heavy, dependable, gear driven

Product Description

PTO shaft with slip clutch is included with each tiller:
series 4 with 48" and 60", series 5 with 72", series 6 with 84"

UL48 Specs:

  • Total width: 53"
  • Tilling width: 48"
  • Tractor HP range: 20-25 HP
  • 6 flanges on rotor
  • 36 tines
  • Size of blades: 16 x 11.5 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 245 RPM
  • Maximus working depth: 6.5"
  • Roor tube diameter: 7 cm
  • Rotor swing diameter: 37.5 cm
  • Weight in crate: 562lb

UL60 Specs:

  • Total width: 65"
  • Tilling width: 60"
  • Tractor HP range: 25-40 HP
  • 7 flanges on rotor
  • 42 tines
  • Size of blades: 16 x 11.5 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 245 RPM
  • Maximus working depth: 6.5"
  • Roor tube diameter: 7 cm
  • Rotor swing diameter: 37.5 cm
  • Weight in crate: 610lb

UM72 Specs:

  • Total width: 77.5"
  • Tilling width: 72"
  • Tractor HP range: 25-50 HP
  • 9 flanges on rotor
  • 54 tines
  • Size of blades: 18 x 11.8 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 241 RPM
  • Maximus working depth: 7"
  • Roor tube diameter: 7.6 cm
  • Rotor swing diameter: 43.4 cm
  • Weight in crate: 928lb

UH84 Specs:

  • Total width: 90.25"
  • Tilling width: 84"
  • Tractor HP range: 50-65 HP
  • 9 flanges on rotor
  • 54 tines
  • Size of blades: 18 x 11.8 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 241 RPM
  • Maximus working depth: 7"
  • Roor tube diameter: 3.5"
  • Rotor swing diameter: 19"
  • Weight in crate: 992lb
PTO shaft with slip clutch is included with each tiller:
series 4 with 48" and 60", series 5 with 72", series 6 with 84"

UL48 Specs:

  • Total width: 53"
  • Tilling width: 48"
  • Tractor HP range: 20-25 HP
  • 6 flanges on rotor
  • 36 tines
  • Size of blades: 16 x 11.5 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 245 RPM
  • Maximus working depth: 6.5"
  • Roor tube diameter: 7 cm
  • Rotor swing diameter: 37.5 cm
  • Weight in crate: 562lb

UL60 Specs:

  • Total width: 65"
  • Tilling width: 60"
  • Tractor HP range: 25-40 HP
  • 7 flanges on rotor
  • 42 tines
  • Size of blades: 16 x 11.5 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 245 RPM
  • Maximus working depth: 6.5"
  • Roor tube diameter: 7 cm
  • Rotor swing diameter: 37.5 cm
  • Weight in crate: 610lb

UM72 Specs:

  • Total width: 77.5"
  • Tilling width: 72"
  • Tractor HP range: 25-50 HP
  • 9 flanges on rotor
  • 54 tines
  • Size of blades: 18 x 11.8 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 241 RPM
  • Maximus working depth: 7"
  • Roor tube diameter: 7.6 cm
  • Rotor swing diameter: 43.4 cm
  • Weight in crate: 928lb

UH84 Specs:

  • Total width: 90.25"
  • Tilling width: 84"
  • Tractor HP range: 50-65 HP
  • 9 flanges on rotor
  • 54 tines
  • Size of blades: 18 x 11.8 x 6 CM
  • PTO input speed: 540 RPM
  • Rotor shaft speed: 241 RPM
  • Maximus working depth: 7"
  • Roor tube diameter: 3.5"
  • Rotor swing diameter: 19"
  • Weight in crate: 992lb

Quality & Warranty

We know that when it comes to farming quality cannot be compromised. Quality control is the core value of Cosmo philosophy and Cosmo regularly collects feedback from customers to improve its machines. Virtually all components are made in house, incl. blades, gears and gearboxes. The blades on the 48" and 60" models are 6mm thick, while on the 72" model they are 7mm. You will notice the quality of welding as soon as you open the crate. Other notable points include boron-treated blades, gear drives (not chain drives), and a high quality PTO shaft with slip clutch that is included with each tiller. You can expect the Cosmo tiller to provide seamless performance for years. We provide a 1 year warranty on parts which is very rarely needed. This warranty applies only to the original buyer (the one that purchased the tiller from us) and starts from the date of delivery or pick up. It does not need to be registered, all tillers are automatically covered. If parts are needed please contact us.

Value

pour tillers represent remarkable value! The reason we are able to offer our prices is because we import our tillers in full containers directly from the manufacturer and ship them to customers across USA from our NJ warehouse. There is no middleman between us and the farmer. We feel that too much farming equipment these days is offered via inefficient supply chains with the result that farming - and food - become unnecessarily more expensive. The shorter the supply chain the better the end prices. We only sell tillers that we physically stock. We treat each order individually with a dedicated shipping specialist researching best shipping options to each location. This is how we make a living!

Watch Videos from Real Users in USA!

More about Cosmo Rotary Tiller

Free Shipping

Freight shipping (WITHOUT LIFTGATE SERVICE) in the lower 48 states is included in our prices, excluding any islands off the US coast (in WA, MA etc).

In Stock

We realize agricultural work can't wait and the importance of keeping equipment in stock is paramount! This is why we maintain a large inventory of tillers at our NJ warehouse, ready for immediate shipping.

Specs & Manuals

you will get A manual book with the product and you can also download from our website.
